Family of Protoneuridae 原蟌科

Borneo has 18 species in two genera, Elattoneura and Prodasineura. All are small, of slender build, with narrow, hyaline, sometimes lightly tinted wings, rounded at the tip. Venation is reduced, with the anal vein entirely lacking or represented as a short anal bridge. The quadrilateral is long and rectangular.

The pterostigma is usually dark and never very long (at most about 1.5 times as long as broad), most commonly lozenge- or diamond-shaped.

The male abdomen is of moderate length, about 1.5 times the length of the hind wing; the female abdomen is only a little shorter and more robust. Most species are marked in either red, orange or blue or are unmarked. The ground color is usually matt black, only occasionally with a bronzy sheen.

Male anal appendages are robust and squat, typically about as long as the last abdominal segment. The upper pair usually have a strong ventral spine but this may be difficult to interpret when its inner margin is hidden behind the tenth segment. The short lower pair often terminate in a thin distal process curling inwards. Although male terminalia of the different species are similar in general form, slight differences can be very useful in diagnosis. Likewise the posterior lobe of the female prothorax varies considerably and can be a good character for separating close species.

Backwater of a small clear stream in dipterocarp forest.

Backwaters of small clear streams in dipterocarp forest.

Most protoneurids are found near slowly flowing water in swampy places沼澤地, in sluggish streams 緩慢的溪流 or in backwaters 死水 of fast running rivers. They are almost confined to forested areas in the lowlands. Although they are often abundant, little is known of their biology. Females oviposit in root masses under banks, typically in tandem with the male erect in the 'sentinel' position, but sometimes alone. The larvae are short and stout with broad heads and proportionally long legs. The caudal lamellae are flattened, short, broad and rounded with the central gill shorter than the lateral ones. Mouthparts, including the mask and its arrangement of setae, are basically similar to those found in some Coenagrionidae and it may be difficult to separate larvae of these families. They are found in silty areas and among root masses.

Five species of Elattoneura are known from Borneo. E. analis is superficially like the common Prodasineura verticalis. The two species are sometimes found flying together, but they differ significantly in color and markings and have slightly different venation. In particular the male of analis has a prominent orange spot at the tip of the abdomen which is lacking in P. verticalis, and the orange color is less intense. E. analis is sometimes quite common on backwaters of small clear streams in dipterocarp forest but it also occurs in alluvial and freshwater swamp forest, especially around Pamlcmus, where males are often found resting among the foliage. In immature the orange color is replaced by pale blue. Also locally common is E. aurantiaca (not illustrated). It is mainly golden yellow-orange with a broad metallic blue-green band on the dorsum of the synthorax. It looks superficially rather like the common coenagrionid Teinobasis rajah but it is more slightly built and has very different wing venation, notably the strong reduction of the anal vein. It is found locally in all types of swamp forest but is probably more common in the south. The three remaining species are seldom encountered and are more or less confined to swamp forest in the southern and western parts of the island. E. longispina is very similar to E. analis in its markings but the ventral spine on the superior anal appendage of the male is exceptionally long and thin . On average it is a little smaller than E. analis. E. coomansi is a very fine, mainly dark species from the west and E. erythromma is a small, fine insect with dark russet antehumeral bands from the south. In life, its eyes are red.

Of the many species of Prodasineura, one of the most widely encountered is the strongly orange-striped P. verticalis . Similar marking occurs in the female but is paler and somewhat reduced. It is found in a wide range of lowland forest but is most common on small to medium-sized streams in mixed dipterocarp forest. It often perches on riverside vegetation, including Pinanga and Pandanus, but when on the wing it can be extremely inconspicuous.

Females generally oviposit alone, typically in root masses in the riverbanks . Several other species have predominantly linear orange markings on the thorax including P. hosei and P. peramoena both recorded from peat swamp and dipterocarp forest streams in west and north-west Borneo.

Protoneuridae includes some 240 species found throughout the world's tropics. In Borneo there are 18 species in two genera, Elattoneura and Prodasineura.

All are small ( hw, 16-20 mm), of slender build, with narrow, hyaline, sometimes lightly tinted wings, rounded at the tip. Venation is reduced, with the anal vein entirely lacking or represented as a short anal bridge. The quadrilateral is long and rectangular.

♂34mm
2022-08-11 MELANGKAP
*Endenmic of Borneo
Kg Melangkap Tiong
-------------------------------------

Prodasineura verticalis is one of the most slender damselfly in Borneo.

♂37mm Juvenile
♀37mm Juvenile

2017-05-30 SG TAWAU
-----------------------------------

Here are index to damselflies sorted according to colour for our quick identification:

Out of the global 10 families of damselflies, the following 7 families are found in Borneo Island :

Damselfly head include :
1- compound eyes,
2- ocelli,
3- antennae,
4- mouth structures
